Victron BMV-712 Smart Battery Monitor - BAM030712000

151,25

TAXES INC.

With integrated Bluetooth connectivity, the Victron BMV-712 Smart Battery Monitor is ready for the era of the Internet of Things. Thanks to its wireless connection, it can communicate with other Victron products to simplify installation and improve performance.

Producto disponible para la venta
Finance your purchase with Cetelem
Reference: BAM030712000 Categories: , ,

Product information

BMV-712 Smart Victron Battery Monitor

Integrated Bluetooth

With integrated Bluetooth connectivity, the BMV-712 Smart Battery Monitor is ready for the era of the Internet of Things. Thanks to the fact that most of the other products from Victron Energy have integrated Bluetooth, wireless communication between them simplifies the installation of systems and improves their performance.

Download the Victron Bluetooth app

Use your smartphone or other Bluetooth-enabled device to:
- customise the settings,
- to consult all important data on a single screen,
- view historical data
- update the software as new functions are added.

Easy to install:

All electrical connections are made to the power shunt's quick connect PCB. The shunt is connected to the monitor via a standard RJ12 telephone cable.
Included: RJ 12 cable (10 m) and battery cable with fuse (2 m); no more required.
Also included is a front screen trim plate, square or round, a rear fixing ring and screws for front mounting.

Midpoint tension control

This function is generally used to monitor large battery banks at a high cost. With the Victron BMV-712 Smart Battery Monitor we can monitor this parameter for a much lower cost. A battery bank consists of a string of cells connected in series. The midpoint tension is the tension obtained in the middle of this chain. Ideally, the mid-point voltage would be exactly half of the total voltage. However, in practice, deviations will be seen depending on many factors, such as the different state of charge of new batteries or cells, their different temperatures, internal leakage currents, capacities and much more.
Significant or increasing deviations from the mid-point voltage indicate improper maintenance or failure of a battery or cell. Corrective action taken after a mid-point voltage alarm can prevent possible damage to a battery.

Low battery current drain

Power consumption: 0.7Ah per month (1mA) @ 12V and 0.6Ah per month (0.8mA) @ 24V

In particular, Li-Ion batteries are virtually depleted of their capacity when they are discharged to the low-voltage cut-off level.

After low voltage disconnection of the cells, the reserve capacity of a Li-ion battery is approximately 1Ah per 100Ah capacity. The battery will be damaged if the remaining reserve capacity of the battery is removed. A residual current of 10mA, for example, can damage a 200 Ah battery if the system is left in a discharged state for more than 8 days.

Bistable alarm relay

Prevents the current drain from increasing in the event of an alarm.

Other BMV-712 Smart Victron Battery Monitor functions

- Voltage, current, power, ampere-hours consumed and state of charge of the battery

- Remaining autonomy at current discharge rate.

- Programmable visual and audible alarm

- Programmable relay, to disconnect non-critical loads or to start a generator if necessary.

- 500 amp quick connect shunt and connection kit

- Selection of shunt capacity up to 10,000 amps

- VE.Direct communication port

- Stores a wide range of historical data that can be used to assess usage patterns and battery condition

- Wide input voltage range: 6.5 Ț "70V

- High current measurement resolution: 10 mA (0.01A)

- Additional input for measuring voltage (from a second battery), temperature or mid-point voltage and corresponding alarm and relay settings.

Datasheet Battery Monitor BMV-712 Smart Victron - BAM030712000

See BMV-712 Battery Monitor BMV-712 Smart Victron - BAM030712000 datasheet

Additional information

Weight1 kg
Dimensions7 × 3 × 7 cm
