Inverter Charger Victron Multiplus II 12V/4000VA 160A-32 230V - PMP122405010

Inverter Charger Victron Multiplus II 12V/4000VA 160A-32 230V - PMP122405010

The Victron MultiPlus II 12/4000 is a powerful, versatile and extremely reliable hybrid inverter-charger designed to efficiently and safely manage and distribute AC power.

This inverter integrates three key functions in a single unit: a power inverter (12 V DC → 230 V AC), a high-current battery charger and an automatic AC transfer switch with UPS function, ensuring a continuous power supply at all times.

Thanks to its robustness and flexibility, the MultiPlus II 12/4000 is an ideal solution for domestic and professional installations as well as for marine applications, stand-alone PV systems, motorhomes, campers and back-up power systems.

Main features of the Multiplus II 12/4000

High performance

The MultiPlus II provides pure sine wave power, making it perfect for powering sensitive equipment such as computers, pumps, household appliances and advanced electronics.

In the event of mains failure or generator disconnection, the inverter automatically switches to battery mode within milliseconds, without perceptible outages, ensuring continuous operation of the connected equipment (UPS function).

Smart charger

This Multiplus II incorporates an intelligent, adaptive battery charger, capable of automatically adjusting charging profiles according to the state and type of the battery bank, maximising performance and extending battery life.

In addition, it allows the charging of auxiliary batteries, such as starter batteries or secondary systems.

PowerControl

The PowerControl function prevents overloading the mains or the generator.

The system intelligently regulates battery charging when AC demand exceeds the set limit, ensuring safe and efficient use of available energy.

PowerAssist

Thanks to PowerAssist, the Multiplus II 12/4000 can back up the main power supply with battery power at times of high demand, allowing it to cope with consumption peaks without tripping protections or compromising the installation.

Expandable and scalable

This inverter-charger can work in parallel with other MultiPlus II inverter-chargers to increase the available power, or be configured in three-phase systems, offering a scalable solution for both residential and industrial installations.

Compatibility

The MultiPlus II is compatible with virtually any 12 V battery on the market. Its great configuration flexibility allows it to be easily adapted to batteries of different technologies, such as lead-acid, AGM, gel or lithium.

Advantages of the Multiplus II 12/4000

The Multiplus II 12V/4000Va inverter-charger offers multiple benefits:

• Uninterruptible Power Supply (UPS): Automatic switchover in less than 20 ms.
• High energy efficiency: Optimises the use of batteries and reduces losses.
• Double AC output: Allows the separation of critical and non-critical loads.
• Advanced energy management: PowerControl and PowerAssist protect limited power supplies.
• Scalable system: Parallel or three-phase connection possible.
• Solar and ESS integration: Fully compatible with Victron solar controllers and energy storage systems.

Technical specifications of the Inverter Charger Victron Multiplus II 12V/4000VA 160A-32 230V - PMP122405010

Technical information about the Inverter Charger Victron Multiplus II 12V/4000VA 160A-32 230V - PMP122405010

Multiplus II 12V/4000VA Datasheet

Multiplus II 12V/4000VA Manual
